Product Overview
Ashland 1/2 HP Cast Iron Sump Pump – Heavy Duty, High Performance
Keep your basement dry and your home protected with the powerful and reliable Ashland 1/3 HP Sump Pump. Engineered for durability and efficiency, this pump is ideal for residential sump applications where performance and dependability are a must.
Key Features:
- Heavy-Duty Cast Iron Construction
Built to last, the rugged cast iron motor housing ensures long service life, even in the toughest environments. - Powerful PSC Motor
The Permanent Split Capacitor (PSC) motor delivers continuous-duty performance at 3450 RPM, offering consistent operation with thermal protection to prevent overheating. - Clog-Resistant Vortex Impeller
A recessed, thermoplastic vortex impeller allows for smooth handling of solids up to 1/2”, reducing the risk of clogs and maximizing efficiency. - Piggyback Plug for Easy Operation
Comes standard with a piggyback plug for simple manual or automatic operation. - Optimal Liquid Handling
Designed to handle intermittent liquid temperatures up to 104°F, with a recommended pH range of 6-8.
Specifications:
- Discharge Size: 1-1/2” N.P.T.
- Impeller Type: Vortex – Thermoplastic
- Cable Length: 10 ft
- Solids Handling: Up to 1/2”
- Max Liquid Temperature: 104°F (intermittent)
- pH Range: 6–8
Technical Construction:
- Motor Housing: Cast Iron
- Pump Casing: Thermoplastic
- Impeller: Thermoplastic
- Motor Shaft: SS430 Stainless Steel
- Hardware: Stainless Steel
- O-Rings: NBR
- Seal: Single Mechanical, Carbon Ceramic
- Bearings: Upper – 608-2RS | Lower – 6202
Electrical Details:
- Horsepower: 1/2 HP
- Voltage: 115V, Single Phase
- Motor Type: PSC
- R.P.M.: 3450
- Insulation Class: B
- Max Stator Temp: 120°C
- Voltage Tolerance: ±10%
- Motor Protection: Thermally Protected
- Service Factor: 1
